CCV OPM-C60 - OPP-C60;OPM-C60

OPM-C60/OPP-C60
System Manual
PA72P002_en
Edition: 40
Page 47 - 68
Product specific instructions
Confidential
© CCV GmbH - It is not allowed to duplicate or distribute this document without our agreement.
6.3 Technical Data
6.3.1 OPP-C60/OPM-C60
Processor
ARM11 Processor, 532MHz Core, 266MHz DDRII
Operating system : embedded Linux
Front plate
OPP-C60s: vandalism resistant, 3mm thick, Neckline: (101mm *
160mm) INOX, IP65
IK10 (20J) for keypad (border and keys)
IK08 (5J) for display glass
OPP-C60c: vandalism resistant, 3mm thick, Neckline: (82mm *
120mm) INOX, IP65
IK10 (20J) for keypad (border and keys)
IK08 (5J) for display glass
OPP-C60m: vandalism resistant, 3mm thick, Neckline: (100mm *
164mm) INOX, IP65
IK10 (20J) for keypad (border and keys)
IK08 (5J) for display glass
Memory
Basic equipment: 64 kByte SRAM - 128MByte DDRII DRAM -
128MB NAND Flash
Display
OPP-C60s/m: 3,5“ TFT Color-Display 320*240px (Window size
72,7*543,3mm)
OPP-C60c: 2,8“ TFT Color-Display 320*240px (Window size
58,3*43,9mm)
Tastatur
OPP-C60s/m: 20 keys, 4 Softkeys (F1-F4)
OPP-C60c: 16 keys (no Softkeys)
Vandalism resistant
Keys with tactile and acoustic feedback
Environmental
conditions
Operating temperature: -20°C to +70°C
Storage temperature: -25°C to +70°C
Humidity: 10% - 90% without condensation
The electronics are varnished in critical areas to protect against
condensation.
Interfaces
Hardware interfaces
a) Four RS-232 interface:
• POS: connection to the machine or to cashier
• SCR: connection to the Secure or to card reader.
• COM: more devices, for example contactless reader
• MDB: optional ERC interface with Multi-Drop-Bus
b) LAN-Interface: Ethernet, 10Base-T und 100Base-T (auto
and manual selection) Communication protocol TCP/IP
(more on request) e.g. for Host or Service-PC.
c) Two USB Interfaces:
• USB-A: Host connection via ISDN or GPRS Dongle
• OTG-USB: (Mini-USB) for TS3
Protocols:
a) Interface protocol
