page 47 www.centsys.com
COMPLETING THE INSTALLATIONSECTION 8
8.3.3. External Radio Receiver and Loop Detector Wiring
FIGURE 73
Control Card
Loop Detector
External Radio
Receiver
NO
NO
NC
NC
COM
COM
Free-exit Loop
12V/24V -
12V/24V -
12V/24V +
12V/24V +
COM
COM
NO
NO
