SPECIFICATIONSSECTION 2
FIGURE 1. D5 SMART PHYSICAL DIMENSIONS
2. Specications
2.1. Physical Dimensions
2.2. Technical Specications
When the WiZos are removed from their packaging, it is important to remember the
following:
The WiZosarereadytobeused;theyhavejustnotbeenconguredoraddedtoa
network.Congurationiswhattheuser/installerneedstodo.
181mm 275mm
372.5mm
31mm
58mm
1. The current values can be used to determine current consumption for battery life backup calculations.
Input voltage 90V - 240V AC +/-10% @ 50Hz
1
Current consumption (mains) 200mA
Battery charger current output 1.3A
Maximum number of operations per day 150
3,6
Duty cycle - Mains present
2,3
50%
Motor power supply
Battery-driven
(Standard Capacity - 2x12V)
Current consumption (motor at rated load) 13A
Input / Output sink currents (Max. accessory current draw)
I/O 1-4 100mA (12/24V)
I/O 5 and 6 3A (12/24V) 10sec Pulse
TABLE 1
