page 19www.CentSys.com
WIRING DIAGRAMS SECTION 8
8. Double Wired Closing Safety Beams
FIGURE 10. DOUBLE WIRED CLOSING SAFETY BEAMS
12V/24V
12V/24V
Wired
IRB
Transmitter
Wired
IRB
Transmitter
12V/24V
12V/24V
IRB Receiver
IRB Receiver
12V/24V
12V/24V
COM
COM
N/C
N/C
N/O
N/O
12V/24V
12V/24V
i5 Wired
Safety Beams
i5 Wired
Safety Beams
