GENERAL DESCRIPTION SECTION 1
The VANTAGE, VERT-X and VECTOR2 operators have been designed to safely and
cost-eectivelyautomateawidevarietyofswinggates,fromsinglelight-domesticswing
gates to heavy industrial double swing gates.
Thefail-safeandfully-redundantPositionandCollisionDetectionsystemhasbeen
designed and tested to set the standard in safety of operation and to provide an
unparalleled level of reliability and durability in operation.
ThegateTravelLimitsaremanagedbyasealeddouble-redundantopto-electronicsystem
thathasbeendesignednotonlytoensureultra-reliableoperation,butalsotoensure
precise position and trajectory control. This enables very accurate and reliable collision
detection to ensure safe operation even under trying conditions.
The V-Series electronic Controller has been designed to be easy and intuitive to use,
with helpful instructions on the status of the operation being given both during and after
theinstallation.Italsohasbuilt-indiagnosticproceduresthatcanverifyeveryaspectof
the control card onsite.
SomeoftheadvancedfeaturesoeredbytheV-Series Controller are:
• Fullyautomatedsingle-buttonLimitSetupforsingleanddoubleswinggates
• FullgraphicsLCDdisplayprovidesanintuitiveuserinterfacewithbuilt-indiagnosticsto
speed up and simplify the installation process
• Separate safety inputs for infrared beams or photocells on both the closing and opening
directions of the gate
• Advancedclosed-loopspeedcontroltomaintainsafeandreliableoperationoninclined
gates and under windy conditions
• Fully-congurablegateRunProles
• Selectable and adjustable Autoclose with push button override
• Pedestrian Opening (partial opening) with Autoclose
• Free-exitinput
• Positive Close Mode
• Positive Open Mode
• Support for Inward and Outward opening gates
• Multiple Modes of Operation
• Solenoid lock drive output up to 2A
• Holiday Lockout
• A status LED output to indicate the Gate Status remotely
• Pillar Light Control
• Leaf Delay is selectable for either gate leaf
• Onboardcode-hoppingreceiverwithselectiveaddinganddeletingofremotecontrols
