SECTION 15 WIRING DIAGRAMS
15. Holiday Lockout Keyswitch/Keypad
FIGURE 17. HOLIDAY LOCKOUT KEYSWITCH/KEYPAD NORMALLY-CLOSED
Holiday Lockout
Keyswitch/Keypad
(Normally-Closed)
12V
12V
N/C
N/O
COM
1
2
3
4
5
6
7
8
9
Main Features
• SMARTGUARDforhard-wiredinstallations
• SMARTGUARDairforwireless,easyinstallations
• 1000 unique codes using one to ten digits
• Selectively add and delete user codes
• Backup Memory Module
• Limited uses counter
• Fully weatherproof with backlit keypad
