SECTION 17 WIRING DIAGRAMS SECTION 15
17. G-SPEAK Classic+ Intercom
FIGURE 19. G-SPEAK CLASSIC+ INTERCOM
G-SPEAK Classic+
12V-24V
IO4
IO3
GND
IO1
GND
IO2
Main Features
• No wiring back to the house saving the installer both
time and money
• No dedicated, costly intercom handsets are required –
your cellphone becomes your intercom handset
• Answer your intercom from anywhere – so convenient
and also greatly improves security
• Open your gate from anywhere for maximum
convenience
• High-securityaccesscontrol–onlylearned-in,authorised
cellphones can access the system
• Split unit for high security – the GSM control module
resides inside the property
• Weatherproof enclosure for greater reliability
