SECTION 15
WIRING DIAGRAMS SECTION 18
18. G-SWITCH-22 Monitoring & Control
G-SWITCH-22
FIGURE 20. G-SWITCH-22 MONITORING & CONTROL
COM 1
COM 2
N/C 1
N/C 2
N/0 1
N/0 2
GND
IN 1
IN 2
-
+
Main Features
Controltwodierentdevices,suchasopeningyourgate
and your garage from anywhere in the world with 2G GSM
coverage
Monitor by receiving SMS alerts, for example when your
mains power has failed or your alarm has been activated
Communicates with up to 1200 users
Activate devices with Missed Call (free of charge) or SMS
EasysetupandadministrationviaCENTURION’sG-WEB1
online interface, or via your mobile phone. Inputs can be
settoreacttoRisingEdge,FallingEdgeorboth–idealfor
monitoring mains, alarm states, etc.
