27. Description of Terminal Functions
S Sens1
SlaveMotor(MTRS).ConnectstothethinPURPLE wire of the
Slave Motor.
S Sens2 SlaveMotor(MTRS).ConnectstothethinBLUE wire of the Slave Motor.
M Sens1
MasterMotor(MTRM).Connectstothethin PURPLE wire of the Master
Motor.
M Sens2
MasterMotor(MTRM).ConnectstothethinBLUE wire of the Master
Motor.
Sens + Operatorsensorpowerconnection.A5Voutputforconnectingtothethin
REDsensorwireonboththeMTRMandMTRSoperators.
Sens - Operatorsensorpowerconnection.A0Voutputforconnectingtothethin
BLACKsensorwireonboththeMTRMandMTRSoperators.
Safe CLS
ClosingBeamSafetyInput.(Anormally-closedpotential-freeinput.)
As long as a connection between this input and Com is maintained the
Controller will behave normally. When this connection is broken it will
prevent the gate from closing if it is stationary, and will stop and reverse
thegateifitisclosing.Thisinputhasnoeectifthegateisopening.
If the Safe CLS function is not required a link must be tted
between Safe CLS and Com for the Controller to operate normally.
1
Safe OPN
OpeningBeamSafetyInput.(Anormally-closedpotential-freeinput.)
For as long as a connection between this input and Com is maintained
the Controller will behave normally. When this connection is broken it will
prevent the gate from opening if it is stationary, and will stop and partially
reversethegateifitisopening.ThisInputhasnoeectifthegateis
closing.
If the Safe Open and reverse functions are not required a link
mustbettedbetweensafeOpenandComfortheControllerto
operate normally.
1
1. WhensettinguptheControllerforthersttimeorafterafullresetbacktotheFactoryDefault
settings has been performed, the system will electronically override the Safety Inputs and allow
the system to function without the links. However, if safeties are connected to either or both
inputs,thereaftertheremustbeanormally-closedcircuitmaintainedforthesystemtooperate
correctly.I.e.ifSafetyBeamsarettedandthenremoved,thecircuitwhichisaectedmustbe
replacedwithawirelinktocreateanormally-closedcircuit.
LCK/STP
HolidayLockout.(Anormally-closedpotential-freeinput.)Foraslongas
a connection between this input and Com is maintained the Controller will
behave normally. But, when this connection to Com is broken all inputs
are inhibited.
IftheLCKfunctionisnotrequiredalinkmustbettedbetween
LCK and Com.
