SECTION 22 FUSE PROTECTION
22.1. Fuse Protection
The following protection fuses are provided on the system:
Item Type Rating
Main Controller
MotorCircuit-fuseperchannel
Automotive Fuse (25 x 7) 15A
Light circuit 5 x 20mm 3A Fast Blow
Auxiliary supply Electronic fuse
1
-notreplaceable 3A
Charger
Mains Input
Non user replaceable fuse 250mA
TABLE 1
1. Toreset:PoweroControllerforatleastoneminuteandre-applypower 
