Particularly with magnetic locks, ensure that the steady state
current draw calculated over a 24 hour period and added to this,
the quiescent current draw of the Controller, other peripherals and
the usage of the motors, does not exceed the current delivered
bythecharger.Ifnecessary,taseparatesupplytopowerthe
lock using an interposing relay connected to the Sol input.
Light
PillarLightconnection.Thesetwoterminalsprovideanormally-open
potential-freecontactwhichisgenerallyusedtoswitchonaPillarLight
(CourtesyLight).Thiscontactisfuse-protected-refertopage 34 for
Fuse Protection details.
Batt +
Positive battery connection. (Battery terminal normally indicated as + or
RED)
Batt -
Negative battery connection. (Battery terminal normally indicated
as-orBLACK)
MTR M+ Master Motor power connection. (Thick BLUE wire)
MTR M- Master Motor power connection. (Thick BLACK wire)
MTR S+ Slave Motor power connection. (Thick BLUE wire)
MTR S- Slave Motor power connection. (Thick BLACK wire)
