CE+T Power T2S-ETH User Manual

44 – Monitoring T2S - ETH User Manual – v1.4
Catena
Address Description Unit Type
Reserved Phase voltage V/10 S32
Reserved Phase current A/10 S32
Reserved Phase frequency Hz/100 S32
Input Group 2 Phase 1
Reserved Phase true power W S32
Reserved Phase apparent power VA S32
Reserved Phase voltage V/10 S32
Reserved Phase current A/10 S32
Reserved Phase frequency Hz/100 S32
Input Group 2 Phase 2
Reserved Phase true power W S32
Reserved Phase apparent power VA S32
Reserved Phase voltage V/10 S32
Reserved Phase current A/10 S32
Reserved Phase frequency Hz/100 S32
Input Group 2 Phase 3
Reserved Phase true power W S32
Reserved Phase apparent power VA S32
Reserved Phase voltage V/10 S32
Reserved Phase current A/10 S32
Reserved Phase frequency Hz/100 S32
DC Group 1
Reserved Group true power (flowing into system) W S32
Reserved Group voltage V/10 S32
Reserved Group current (flowing into system) A/10 S32
DC Group 2
Reserved Group true power (flowing into system) W S32
Reserved Group voltage V/10 S32
Reserved Group current (flowing into system) A/10 S32
Status (1080-1087):
These entries allow getting the status of power system, power inputs, and loading. The status is the one provided on
web interface, main page, through status “LED”.
Name Description Value
White Missing 0 (bit 00000000)
Grey OFF 1 (bit 00000001)
Green OK. This means the input/output is OK 2 (bit 00000010)
