133
Steam Injector Heat Installation C4/C8,15-30 PSI
(Parts list continued on next page)
1 100003 HEX PLAIN NUT,1/4-20 SST4
2 100007 SCREW,TRUSS HEAD,10-32 x 3/8 SST3
3 100134 ELBOW,STREET,1NPT X 90,MI2
4 100154 HEX PLAIN NUT, 5/16-18 SST8
5 100547 LOCKNUT,1/2" NPT,SST1
6 100734 HEX HEAD,1/4-20 X 1/2 SST2
7 100740 HEX HEAD,5/16-18 X 1 SST8
8 100854 CHECK VALVE,1" NPT BRONZE1
9 102376 WASHER,FLAT,5/16x3/4x.06 SST16
10 102554 UNION,3/4"NPT, SST1
11 105739 ELBOW,REDUCING,1"NPT X 3/4"NPT X 90,M.I.1
12 105780 UNION,1"NPT, MALLEABLE IRON2
13 105847 NIPPLE,1"NPT X CLOSE,B.I.1
14 105853 NIPPLE,1"NPT X 3" LG.,B.I.2
15 105863 NIPPLE,1"NPT X 6 1/2" LG.,B.I. EUCCW 1
15 105853 NIPPLE,1"NPT X 3" LG.,B.I. EUCC 1
16 106013 WASHER,LOCK,5/16 SPLIT,SST 8
17 106026 WASHER,FLAT,1/4x5/8x.06 SST4
18 106482 WASHER,LOCK,1/4 SPLIT,SST6
19 106486 WASHER,LOCK,#10 SPLIT,SST2
20 107033 WASHER,FLAT,.208X.438X.047 SST4
