134
Steam Injector Heat Installation C4/C8,15-30 PSI
27 110005 VALVE, 1" ASCO (NO LONGER AVAILABLE) 1
110007 REPAIR KIT, 1" ASCO VALVE # L8220G007 ONLY A/R
--- 114800 VALVE, 1" ASCO STEAM ASCO # L8220G410 1
114830 REPAIR KIT, 1" ASCO VALVE # L8SS0G410 ONLY A/R
21 107136 SCREW,HEX HEAD,10-32 x 3/8 SS
T2
22 107966 HEX GRIP NUT,10-32 SST W/NYLO
N4
23 107967 HEX GRIP NUT,1/4-20 SST W/NYLO
N2
24 108345 GASKET,HEATER/STANDPIP
E1
25 109069 THERMOSTAT,CONTROL,WITH CAPILLARY 1
26 109683 FLANGE,BLOCKOFF,HEATER/CROSSFLO
W1
28 111371 NIPPLE,TOE,1"NPT X 7"LG.,SS
T2
29 112257 O-RING,55.3 X 66.7 X 5.7 1
30 201041 WASHER,SPACER,7/8x1 3/16x1/8 NP 1
31 201110 STEAM INJECTO
R2
32 321512 CLAMP,STEAM INJECTOR BRACKE
T1
33 323430 BRACKET, THERMOSTATS,USN72,44C
R1
34 329768 COVER,HEATER BOX,C4-BK
T1
35 329769 HEATER BOX WELDMENT,C4-
B1
36 330242 FLANGE WELDMENT,STEAM,C3/C4 HP 1
37 331175 MANIFOLD WELDMENT,EUC-4FT STEAM INJECTOR 1
38 331176 BRACKET,STEAM INJECTOR NIPPLE,C3/C
42
39 331177 BRACKET WELDMENT,STEAM INJECTOR SUPPOR
T1
40 601861 PIPING SUB-ASSY,STEAM INJECTOR,C3/C4 EUCCW 1
--- 601868 PIPING SUB-ASSY,STEAM INJECTOR,C3/C4 EUCC 1
