4. From the right side of the vehicle, reach over to the left side of the factory
steering valve and unplug the factory 2- pin Deutsch enable connector. Plug the
2-pin Deutsch connector in place of the factory connector.
5. The vehicle is equipped with a guidance enable rocker switch, which allows
power to the steering valve. The switch is located on the right hand console This
switch must be set to the ENABLE position in order to auto steer the machine.
NOTE: If this switch is left in the ENABLE position during vehicle start up, it may
need to be cycled off and on to unlock the guidance system.
6. The vehicle is equipped with a guidance engage button. Press the button to
engage/disengage the auto steer system. The operator can either engage the
autosteer with the button switch on the console or with the display.
