78
Portuguese, Latvian, Polish and Ukrainian.
Area Units includes mu, ha, ㎡,acre and da.
Data Source: Demo mode can work when use the CAN Data with PA-3 receiver; Demo
mode can work when use the Simulation Data without PA-3 receiver.
Coverage Logging: Work track need to be opened manually in Switch Mode; Work
track will be opened automatically when entering autopilot in Automatic Mode.
Curve Sample Distance(m): The interval to record points when use curve line. The
default is 2 meters and the minimum can be 1 meter for better smooth. The
maximum points are 1800.
Camera Channel: Currently only the default Channel 5 is available for camera.
