RM238 Series
Backplane ā”‚ 49
Table 10 Fan setting for RM23808
DIP
NC3 (Mute pin)
JA1 (JCK pins)
Fan
ON
PIN 5,6 OPEN
PIN 4,6 SHORT
4
ON
PIN 5,6 OPEN
PIN 2,4 SHORT
2
ON
PIN 5,6 SHORT
N/A (No matter what status is)
3
