Chenbro RM238 Series User Manual

RM238 Series
Backplane │ 64
Figure 83 Backplane rear view
Table 27 Connector and pin header function description
Label
Connector
Description
Drawing
A
Power
The backplane includes two power connectors
supplying 12V input to the backplane. Power is
routed to the backplane via a power cable harness
from the power supply.
B
I2C
The backplane includes one 4-pin connector used as
a management interface to the server board.
