Troubleshooting Edge/Edge Blanket
6-4
WARNING
Only trained personnel with experience
in electrical or mechanical repair should
troubleshoot and repair the unit.
Troubleshooting
WARNING
Read the REPAIR chapter and make
sure that the power is disconnected
before doing any repairs.
6.8 Discharge Section (cont)
Leading Edge of Flatwork Misaligned ........................................................................6-24
Excessive Gap Between Flatwork Pieces ..................................................................6-24
Machine Stops, Message reads:
TAIL SENSOR COVERED/SHUT DOWN BEFORE CLEARING ........................6-24
Ribbons Do Not Track Straight ..................................................................................6-24
Discharge Conveyor Lift Switch Not Working ............................................................6-24
6.9 Sensor Function
Sensor Function Issue, Message Reads:
SENSOR FAILED/MISALIGNED/ INLET CONVEYOR
SENSOR FAILED/MISALIGNED/ LEFT CORNER
SENSOR FAILED/MISALIGNED/ MATERIAL TAIL
SENSOR FAILED/MISALIGNED/ MATERIAL TAUT
SENSOR FAILED/MISALIGNED/ RIGHT CORNER
SENSOR FAILED/MISALIGNED/ TRANSFER POSITION
SENSOR FAILED/MISALIGNED/ UPPER SPREADER HOME ..........................6-25
Proximity Sensor Not Working ...................................................................................6-25
6.10 CHI Panel
CHI Panel is Not Functioning, No error message ......................................................6-26
CHI Panel is Not Functioning, Message reads:
COMMUNICATION ERROR/FAULTY CODE RETURNED .................................6-26
CHI Panel is Not Functioning, Message reads:
COMMUNICATION ERROR/NO RESPONSE FROM CONTROL ......................6-26
CHI Panel Doesn’t Change Programs .......................................................................6-26
Parameter Error Message, Message reads:
MEMORY ERROR/PARAMETERS WILL DEFAULT ...........................................6-26
Parameter Error Message, Message reads:
MEMORY INITIALIZED/ADJUST ALL PARAMETERS .......................................6-26
6.11 Compressed Air System
No Air Supply to Unit ..................................................................................................6-27
Poor Air Pressure in Unit ............................................................................................6-27
No or Poor Air Supply to Air Devices .........................................................................6-27
Compressed Air Supply System Error .......................................................................6-28
To Next Page
