Edge/Edge Blanket Operating Guidelines
3-9
Flatwork Handling
The way that operators use the feeder is very
important. They can increase productivity, extend
the life of the unit, and most importantly, promote
safety.
Safety
Always follow the site standards to
avoid repetitive motion injury.
If an item jams, do not reach inside the
unit while the power is on. Refer to
Handling a Jam Safely.
If an item falls, leave it until the end of
the batch. Refer to Handling Misfeeds
Safely.
Program Selection
For large pieces, pressing a STATION key
selects a preset program by number and item
type.
On a standard Edge, the presets are for KING
Sheet’s, COTTON and 75/25, and QUEEN
Sheet’s, COTTON and 75/25 (Stations 1-4
respectively).
On an Edge Blanket, the presets are for Heavy
Blankets and Bath Blankets (Stations 1 and 2).
Pressing a STATION key until the light goes
off will shut down the spreader/feeder.
•
•
•
Set Pacing (Option)
If the unit is equipped with the optional pacing
lights, follow theses steps to set the unit to signal
whether the pace is being met during each minute
of operation.
On the CHI Panel, press and hold the AD
-
JUST button; then, press the ENTER but-
ton. Release both buttons. The SELECT
ADJUSTMENT menu displays:
SELECT ADJUSTMENT
INL TRN SPR FEED IRN CHI
The flashing cursor is under CHI.
Press the ENTER button. The Program
Adjustments (CHI) menu displays:
PACE=04 LOWSPRED 200FPM
TORQ.16S AIR.16S GAP-06”
With the CURSOR button under the PACE
setting, press the + or - key as appropriate
to set the desired hourly standard. The
range is from 4 to 20 pieces per minute,
in 1 piece increments.
When the correct value is displayed, press
ENTER.
The SELECT ADJUSTMENT menus
displays. Press ENTER again to return to
normal operation.
1.
2.
3.
4.
5.
