Troubleshooting Edge/Edge Blanket
6-6
WARNING
Only trained personnel with experience
in electrical or mechanical repair should
troubleshoot and repair the unit.
Troubleshooting
WARNING
Read the REPAIR chapter and make
sure that the power is disconnected
before doing any repairs.
Jam Messages
CORNER CLUTCH JAMMED
SHUTDOWN BEFORE REMOVING .........................................................................6-16
TRANSFER CYLINDER JAMMED
SHUTDOWN BEFORE REMOVING .........................................................................6-17
UPPER SPREADER STALLED
SHUTDOWN BEFORE REMOVING .........................................................................6-19
TAIL SENSOR COVERED
SHUTDOWN BEFORE REMOVING .........................................................................6-24
JAM/SENSOR AT LEFT WALL
SHUTDOWN BEFORE REMOVING .........................................................................6-22
JAM/SENSOR AT RIGHT WALL
SHUTDOWN BEFORE REMOVING .........................................................................6-22
JAM/SENSOR AT INLET CONV
SHUTDOWN BEFORE REMOVING .........................................................................6-22
Sensor Messages
SENSOR FAILED/MISALIGNED
INLET CONVEYOR ...................................................................................................6-25
SENSOR FAILED/MISALIGNED
LEFT CORNER ..........................................................................................................6-25
SENSOR FAILED/MISALIGNED
RIGHT CORNER .......................................................................................................6-25
SENSOR FAILED/MISALIGNED
TRANSFER POSITION .............................................................................................6-25
SENSOR FAILED/MISALIGNED
UPPER SPREADER HOME ......................................................................................6-25
SENSOR FAILED/MISALIGNED
MATERIAL TAIL .........................................................................................................6-25
SENSOR FAILED/MISALIGNED
MATERIAL TAUT .......................................................................................................6-25
