ECO 6 Digital Color Doppler Ultrasound System
41
Activate [Color Invert] and rotate [MENU] to turn on or off. Or press to
realize Color invert.
Activate [Steering Angle] and rotate [MENU] to adjust Steering Angle.
Change type of color map.
Activate [Color map] and rotate [MENU] to adjust D color map.
Press parameter control key on [Wall Filter] to change Wall Filter.
Activate [Wall Thre.] and rotate [MENU] to adjust Wall Thre.
Activate [Blood Effection] and rotate [MENU] to adjust Blood Effection,
adjustment range Smooth/Resolution.
The line density has two types: high density and low density. High density means
better image quality while low density image has higher frame rate.
Turn on / off the B/BC Mode. Rotate [MENU] to activate this mode.
Please refer to the PostProcess of B Menu adjustment.
Activate the [Slide show] to enter into slide show mode.
In real status, press the corresponding key of [Compound] to adjust.
Adjust the position of baseline.
Press parameter control key on [Baseline] to change position of baseline.
Activate [PRF] and press the corresponding key to adjust PRF.
Activate persistence and press parameter control key to adjust.
5.8 PW / CW Image Adjustment
5.8.1 Parameters in PW Mode
Activate D 2D Map and rotate [MENU].
Activate [Spectrum Enhance] and rotate [MENU] to adjust Enhance.
Activate [Dynamic Range] and rotate [MENU] to adjust Dynamic.
Adjust the type of the chroma.
Press parameter control key on [Wall Filter] to adjust wall filter.
Adjust audio volume.
Activate [Audio] and rotate [MENU] to adjust audio volume.
Press parameter control key on Invert, or press key to invert spectrum.
Please refer to the PostProcess of B Menu adjustment.
Activate the [Slide show] to enter into slide show mode.
