ECO 6 Digital Color Doppler Ultrasound System
69
6.8 GYN Measurement
GYN measurement includes measurement of UT-D (uterus diameter), ENDO (endometrium), CX-L (Uterine
cervix length), LEFT OV and RIGHT OV (volume of left and right ovary) and LEFT FO and RIGHT FO (left
and right follicle). The result will be calculated and displayed automatically on the screen by measuring
relevant parameters.
Freeze the required image under GYN examination, then press [Calc] to enter into GYN measurement status.
Meas. Menu
Submenu
Unit
Meas. Method
Comment
Distance
cm
Refer to distance
Meas.
UT
UT_L
cm
Refer to distance
Meas.
CX_L
cm
Refer to distance
Meas.
UT_W
cm
Refer to distance
Meas.
UT_H
cm
Refer to distance
Meas.
Cervix Vol.
ml
Refer to distance
Meas.
Formula: V＝
(π/6)×L×H×W
L: Cervix _L
H: Cervix _H
W: Cervix _W
ENDO
cm
Refer to distance
Meas.
Ovary (L/R)
ml
Refer to distance
Meas.
Formula: V＝
(π/6)×L×H×W
L: OV _L
H: OV _H
W: OV _W
Follicle (L/R)
Follicle width
cm
Refer to distance
Meas.
Follicle height
cm
Refer to distance
Meas.
Follicle Length
cm
Formula of 2distance
V＝（π/6）×A×B
2
Formula of 3distance
V＝（ π/6）×L×H×W
L: follicle length
H: follicle height
W: follicle width
6.9 Small Parts Measurement
Freeze the required image under Small parts examination, then press [Calc] to enter into small parts
measurement status.
