ECO 6 Digital Color Doppler Ultrasound System
43
5.9 M Image Menu & Parameters Adjustment
This function includes post processing, slide show and other items. Press
[MENU] knob, then choose Utility selection, it will appear Utility options.
Adjust the type of the chroma.
Choose [2D Map], and rotate [MENU] button to select the scale curve type.
Adjust image gray value parameters.
Adjust image gray scale inhibition parameters
Choose [B Rejection], and rotate [MENU] button to adjust B Rejection
parameters.
Press this menu to exit the postprocess.
Press parameter control key on [Speed] to adjust speed.
Adjust the chroma of M mode.
Activate M 2D Map and press corresponding parameter keys to adjust.
Adjust image gray value parameters.
Press corresponding keys to adjust the layout to LR or UD.
5.10 CPA/DPD/TDI Image Adjustment
Activate B Mode and press parameter key on CPA to enter into CPA Mode. Then press [MENU] to display
CPA Menu and move cursor to DPD to change the menu to DPD Menu.
5.10.1 CPA & DPD Parameter and Menu Adjustment
Move cursor on [Wall Filter] and rotate the [MENU] to adjust wall filter.
Activate [Wall Thre.] and rotate [MENU] to adjust Wall Thre.
Activate [Blood Effection] and rotate [MENU] to adjust Blood Effection,
adjustment range is Smooth/Resolution.
The line density has two types: high density and low density. High density
means better image quality while low density image has higher frame rate.
Please refer to the Utility of B Menu adjustment.
Only can be adjusted on DPD Mode. Invert the color of flow
Activate [Color Invert] and rotate [MENU] to turn on or off. Or press
to realize Color invert.
