ECO 6 Digital Color Doppler Ultrasound System
42
In real status, press the corresponding key of [Freq] to adjust.
Adjust the position of baseline.
Press parameter control key on [Baseline] to change position of baseline.
Activate [PRF] and rotate Menu to Adjust PRF.
Activate [Triplex Mode] and press the first line key to turn on or off.
Press parameter control key on [Speed] to adjust speed.
Image mode and can be activated only for the phased array probe.
Image mode and can be activated only for the phased array probe.
5.8.2 Parameters in CW Mode
Press to select the phased array probe and the examination part, then the CW Mode can be activated.
Activate B Mode and press the parameter key on [CW] twice to enter into the CW Mode.
In real status, rotate [GAIN] knob to adjust the Gain.
Press [ANGLE_ZOOM] selection knob and then rotate the knob to change the
angle of sample gate.
Press the key, the displayed image is reversed in the right-left horizontal
direction.
Press the key, the displayed image is reversed in the up-down vertical
direction.
Turn ON/OFF THI function.
Press the [AIO] knob to activate the AIO function.
In real status, press the corresponding key of [Freq] to adjust.
Adjust the position of baseline.
Press parameter control key on [Baseline] to change position of baseline.
Activate [PRF] and press the corresponding key to adjust PRF.
Press parameter control key on [Speed] to adjust speed.
Activate D 2D Map and rotate [MENU].
Activate [Spectrum Enhance] and rotate [MENU] to adjust Enhance.
Activate [Dynamic Range] and rotate [MENU] to adjust Dynamic.
Adjust the type of the chroma.
Press parameter control key on [Wall Filter] to adjust wall filter.
Adjust audio volume.
Activate [Audio] and rotate [MENU] to adjust audio volume.
Press parameter control key on Invert, or press key to invert
