Meas. Menu
Submenu
Unit
Meas. Method/
Meas. Formula
Comment
LAD
cm
Refer to M Distance Meas.
LVPEP/LVET
Refer to M Time Meas.
AA
cm
Refer to M Distance Meas.
Tricuspid
Valve
RVOT Diam
cm
Refer to M Distance Meas.
RA Diam
cm
Refer to M Distance Meas.
D-E Exc Dist
Refer to M Velocity Meas.
E-F Slope
Refer to M Velocity Meas.
A-C Int Time
Refer to M Velocity Meas.
Pulmonary
Valve
RVPEP
RV/LV
RVET
Refer to M Time Meas.
A wave Amp
cm
Refer to M Distance Meas.
B-C Slope
Refer to M Velocity Meas.
RV/LV
RVIDd
cm
Refer to M Distance Meas.
LVIDd
cm
Refer to M Distance Meas.
LV Massd
IVsd
cm
Refer to M Distance Meas.
LVIDd
cm
Refer to M Distance Meas.
LVPWd
cm
Refer to M Distance Meas.
TAPSE
cm
Refer to M Distance Meas.
6.19 M Urology Measurement
Refer to general measurement in M mode.
6.20 M Small Parts Measurement
Refer to general measurement in M mode.
6.21 M Pediatric Measurement
Refer to general measurement in M mode.
6.22 PW mode measurement methods
Activate PW mode, and then press [Calc] and [Change] to enter PW mode measurement.
Note:
 In order to get accurate result, the PW image must be clear and high quality.
 Insure that you have fixed the cursor at the exact place of cardiac systole and diastole.
