ECO 6 Digital Color Doppler Ultrasound System
44
In real status, press the corresponding key of [Freq] to adjust.
Adjust the position of baseline.
Press parameter control key on [Baseline] to change position of baseline.
Activate [PRF] and rotate Menu to Adjust PRF.
Activate persistence and press parameter control key to adjust.
5.10.2 TDI Image Adjustment
Press to select the phased array probe and the examination part, then the TDI Mode can be activated
Activate B Mode and press parameter key on TDI to enter into TDI Mode. Then press [MENU] to display TDI
Menu.
In real status, rotate [GAIN] knob to adjust the Gain.
Press [DEPTH_FOCUS] selection knob, and then rotate the knob to change the
depth of image.
Press the key, the displayed image is reversed in the right-left horizontal
direction.
Press the key, the displayed image is reversed in the up-down vertical
direction.
Turn ON/OFF THI function.
Press the [AIO] to activate the AIO function.
In real status, press the corresponding key of [Freq] to adjust.
Adjust the position of baseline.
Press parameter control key on [Baseline] to change position of baseline.
Activate [PRF] and rotate Menu to Adjust PRF.
Activate persistence and press parameter control key to adjust.
Move cursor on [Wall Filter] and rotate the [MENU] to adjust wall filter.
Activate [Blood Effection] and rotate [MENU] to adjust Blood Effection,
adjustment range is Smooth/Resolution.
Move cursor on [Wall Filter] and rotate the [MENU] to adjust wall filter.
Change type of color map.
Activate [Color map] and rotate [MENU] to adjust D color map.
Only can be adjusted on DPD Mode. Invert the color of flow
Activate [Color Invert] and rotate [MENU] to turn on or off. Or press
to realize Color invert.
The line density has two types: high density and low density. High density means
