ECO 6 Digital Color Doppler Ultrasound System
61
The horizontal axis represents the gray scale of the image ranging from 0 to 250.
The vertical axis represents the distribution ratio of each gray scale. The value shown on the top of vertical
axis represents the percentage of the maximally distributed gray in the whole gray distribution.
6.2.5 Profile
Profile is used to measure the gray distribution of the ultrasound signals in the vertical or horizontal direction
on a certain profile (section).
This measurement is only available in the frozen mode.
Measurement steps:
1. Press [Calc] to enter into measurement, press [Change] to switch measurement menu to [General]
measurement.
2. Press [ENTER] on [Profile] menu to enter into measurement status.
3. Draw a straight line at the measuring position. The method is the same as that to measure distance.
4. The calculated result of the profile will be displayed at the center of the screen.
1-The horizontal (or vertical) axis represents the projection of the profile line on the horizontal direction.
2-The vertical (or horizontal) axis represents the gray distribution of the corresponding points on the profile
line.
6.3 B Fast Measurement
Press [Dist] to enter B Fast measurement in B mode. Press the corresponding parameter control key to switch
the fast measurement item.
Meas. Menu
Submenu
Unit
Meas. Method/
Meas. Formula
Comment
Distance
Distance
cm
Refer to distance
Meas.
Ratio(Distance)
Refer to distance
Meas.
Formula:
R=D1/D2
D1: First Distance
D2: Second Distance
Angle
deg
Refer to distance
Meas.
Angle Range:
0°~ 180°
Area
Ellipse
Trace
Ratio(Area)
Auto Cubic Spline
Area cm
2
Circle cm
Refer to Ellipse
and trace meas.
Ellipse and trace.
Volume
Volume (1Distance)
ml
Refer to distance
Meas.
Formula: V ＝
(π/6)×D3
D means: Depth
Volume (1Ellipse)
ml
Refer to ellipse
meas.
Formula: V ＝
(π/6)×A×B2
A: Long Axis
B: Short Axis
