ECO 6 Digital Color Doppler Ultrasound System
59
6.1.4 [DEL]
Main functions are as follows:
In frozen status, press [DEL], delete all the measurement results, comments and traces.
6.1.5 [Change]
Press [Change] to switch other menu;
6.1.6 [Exit]
Press [Exit] to exit the measurement menu.
6.1.7 Parameters control button
Press the corresponding button to update the function and use the function.
6.2 B Mode general Measurement methods
6.2.1 Meas. Distance
Measurement steps:
1. Press the [Calc] button and press [Change] to enter into General measurement. Move the trackball to the
[distance] item on the menu and press [MENU] or press the quick measure button [Dist]; it will display a
segment “+”icon.
2. Move the “+”icon by trackball to fit the one point of the line. Press [ENTER] to fix the start point and the
cursor can be moved to the next position.
3. Press [UPDATE] can change the activated point, and fit the other point of the line.
4. Move the cursor to the end-point, press [ENTER] again to complete the measurement.
5. After the measurement, the result will display in the measurement results area.
6. Repeat the steps from 1 to 4 to start next “distance” measurement. Press [DEL] to delete all the
measurements.
Note:
Each group of measurement is limited, if the measurement results beyond, it will begin a new group of
measurement automatically.
6.2.2 Ellipse
Measurement steps:
1. Press the [Calc] button and press [Change] to enter into General measurement. Then move trackball to the
[Perimeter/Area<Trace>] and press [UPDATE] to change it to [Perimeter/Area<Ellipse>] in the menu and
it will display a segment “+”icon.
2. Move the “+”icon by cursor, Press [ENTER] to fix the point and the cursor can be moved to form a round.
3. Press [UPDATE] can exchange the activated point and the fixed point.
