Ground Bond Tester 19572 User’s Manual
2-2

Ambient Temperature and Relative Humidity
 Specifications Range
18 to 28°C (64 to 82°F),
≤
70% RH.
 Operable Range
Maximum relative humidity 80% for temperature up to 31°C
(88°F). Decreasing linearly to 50% relative humidity at
40° C (104°F)
Altitude up to 2000m.
Indoor use only.
Pollution degree 2

Storage Range
-10 to 60°C (-14 to 140°F),
≤
90% RH.

Installation Category
CAT II

Power Requirement

Line Voltage
AC 100V, 120V, 220V ± 10%, 240V -10% ~ +5%

Frequency
50 or 60 Hz

Power Consumption
No load: < 100VA, With rated load: 880W MAX.

Dimension
320W x 105H x 400D mm

Weight
< 16 kg.

Safety

Ground Bond
Less than 100m
Ω
at 25Amp, 2sec

Hipot
Less than 5mA at 1.8kVac, 3sec

Insulation Resistance
Over 20M
Ω
at 500V 3sec

Line Leakage Current
Less than 3.5mA at 127V, 2sec, normal, reverse
Note
1. For full rating output, the line input range is +10%, -5%.
2. 40 amp for TUV 120 seconds, 40.1 – 45amp continue is 60 seconds.
The maximum test resistance range is with offset value 510mΩ, at 8amp
output.
3. For getting the optimal accuracy, please use the 4-wire type for measuring.
It is no need to do offset again. When offset value is lower than 10mΩ, it is
over test specification. By using offset can increase 5mΩ maximum
specifications error.
