Programmable AC Source 61501/61502/61503/61504 User’s Manual
5-8
If the AC Source is in output status, press OUT/QUIT, the output will quit waveform to zero
voltage. Then, if press OUT/QUIT again, the AC Source only out the waveform set in MAIN
PAGE. Users must press ENTER to trigger again. Or if in quit status, users can press
ENTER to output STEP waveform directly.
The STEP wave will stop to execute when press
PAGE/EXIT to exit STEP execution page.
When TRIG = MANUAL, the LCD shows TRIG_UP and TRIG_DOWN. The output
waveform is changed to the next step if TRIG_UP is selected. The output waveform is
changed back to last step if TRIG_DOWN is selected.
STEP mode example:
_TRIG_ON * STOP * [ STEP ]
V = 0.00 F = 0.00 I = 0.00 S
P
= 0.0 PF
= 0.000 CF = 0.00
T
_TRIG_OFF * RUNNING * [ STEP ]
TRIG_PAUSE
V = 0.00 F = 0.00 I = 0.00 S
P
= 0.0 PF
= 0.000 CF = 0.00
T
_TRIG_CONTINUE * PAUSE * [ STEP ]
V = 0.00 F = 0.00 I = 0.00 S
P
= 0.0 PF
= 0.000 CF = 0.00
T
_TRIG_UP * STOP * [ STEP ]
TRIG_DOWN
V = 0.00 F = 0.00 I = 0.00 S
P
= 0.0 PF
= 0.000 CF = 0.00
T
COUNT = 3 DWELL = 60.0 ms [ STEP ]
Vac = 40.0 F = 50.00 Vdc = 0.0
dV = 10.0 dF = 50.00 dDC = 20.0
<SHIFT><ENTER> to Execute
T
