Programmable AC Source 61605 User’s Manual
1-2
Model
61605
AC OUTPUT RATING
Max. power
4000 VA
Voltage
Range
150V / 300V / Auto
Accuracy
0.2 % + 0.2 %F.S.
Resolution
0.1 V
Distortion
0.3 % @50/60Hz, 1 % 15- 1K Hz
Line regulation
0.1 %
Load regulation
0.2 %
Temp. coefficient
0.02 % per degree from 25°C
Maximum current
r.m.s.
32A / 20A
peak
192A / 96A
Frequency
Range
DC, 15-1K Hz
Accuracy
0.15 %
DC OUTPUT RATING
Power
2000W
Voltage
212V / 424V
Current
16A / 8A
INPUT RATING
Voltage range
190-250V three phase
Frequency range
47-63 Hz
Current
14A Max. per phase
Power factor
0.98 Min.
MEASUREMENT
Voltage
Range
150V / 300V
Accuracy
0.2 %+0.2 %F.S.
Resolution
0.1 V
Current
Range (peak)
192A
Accuracy (r.m.s.)
0.4 %+0.3 %F.S.
Accuracy (peak)
0.4 %+0.6 %F.S.
Resolution
0.01 A
Power
Accuracy
0.4% + 0.4 % F.S.
Resolution
0.1 W
OTHERS
Efficiency
83 %
Size (WxHxD)
483 mm x 268 mm x 610 mm
Weight
36 Kg
Protection
UVP, OCP, OPP, OTP, FAN
Temperature Range
Operation
0 °C to 40 °C
Storage
-40 °C to 85 °C
Humidity
30 % to 90 %
Safety & EMC
CE
