Local Operation
3-19
1. The DEGREE of MASTER is 0, and the DEGREE of SLAVE is 120,
it means the SLAVE is 120 degree lead of MASTER.
2. The first cycle of SLAVE waveform will be distorted if the DEG ON
(output on degree, see 3.7.2) doesn’t be set correctly. For
example, if the MASTER DEG ON = 90, the DEG ON of SLAVE
must be 210 (120 + 90 = 210).
3. Another SLAVE must DEG ON = 330 (240 + 90 = 330).
1. If the DEG OFF (quit degree, see 3.7.2) of MASTER and SLAVE are
IMMED, the MASTER phase angle will quit on zero degree, and the
SLAVE will quit on 120 or 240 degree. But if users assign quit
