Programmable AC Source 61605 User’s Manual
3-14
2. Turn RPG to select “YES”, and then ENTER.
APPLY=YES_
3.7 OUTPUT Functional List
On CHOICE PAGE (see 3.4), press 3 then press ENTER, choose the OUTPUT functional
list.
Press
SHIFT
, then

to change to next page.
3.7.1 COUPLE Mode of Output (AC+DC, AC, DC)
There are three couple mode of AC source output: AC+DC, AC and DC. The user can set
COUPLE on OUTPUT functional list (see 3.7) to fit the application. Then, the display of
MAIN PAGE will change corresponding to the mode.
The procedures of setting from AC+DC to AC are shown as below:
1. Move the cursor to the command of "COUPLE=" COUPLE = AC+DC_
2. Turn RPG to change the option from AC+DC to AC,
then press ENTER. COUPLE = AC
The DC mode of AC source is applied to doing some voltage tests. The
AC source has not such many output capacitors; some features like
voltage ripple, load transient, are not as good as DC source. But it can
PAGE CHOICE = 3_
1. SETUP 2.CONF 3.OUTPUT 4. MANUAL CALI
COUPLE = AC+DC_ DEG : ON= 0.0 OFF=IMMED
Vs (V/ms) = 0.000 Fs (Hz/ms) = 0.000

DCs (V/ms) = 0.000 ON_S/R = OFF

HIGH VOLTAGE OPTION = NONE
[ OUTPUT ]
3-PHASE MODE = OFF

DEGREE = 0.0

