Installation
2-3
Figure 2-2 380 3∼Y Input Connection
Figure 2-3 Input Terminal Cover
2.4 Output Connection
The output terminal block is located in the rear of the AC source. Load connecting to the "N"
and "L" is done at the output terminals. To meet the safety requirements, the safety cover
must be fasten. The wires to the load must be sufficiently large gauges, so they will not
overheat while carrying the output current. Please see figure 2-3 on the next page.
Output terminal labeled "L" is the "+" terminal, terminal labeled "N" is the
"-" terminal when output voltage contains DC composition.
