Local Operation
3-23
The cursor stays in channel 1. The user can press 1 - 9 to select channel or use
, , or press SHIFT then to change page to the destination. The cursor stays
in channel 2. after pressing 2 . The display is shown as below.
Press ENTER, the display return to MAIN PAGE automatically. And the output settings are
Vac = 120, F = 60, Vdc = 0, just as the settings saved in memory channel 2.
If the recalling setting is output of RANGE or over the V LIMIT (see 3.5.2, 3.5.3), the display
will show the following:
Press ENTER to return to recall page. Check if the settings violating the RANGE or V LIMIT.
1. Saving and recalling output settings are acted for MAIN PAGE
setting only, the other parameters are ignored.
2. In different couple mode of output (see 3.7.1), the lack of settings will
be regular to Vac=0V, F=60Hz, Vdc=0V automatically. For
example, in DC output mode, Vac=0V, F=60Hz, Vdc is the setting
value in MAIN PAGE as running the SAVE function.
3.8.2 Save and Recall System Data
The AC source offers three memory groups for the user to save system data and to recall
them for later use. The system data includes all parameters in function list like SETUP (see
3.5), CONF (see 3.6) and OUTPUT (see 3.7). In the CHOICE PAGE (see 3.4
), press SHIFT,
then PAGE/EXIT, to run the SAVE function. The displays are shown as below.
CHOICE 1 - 9, PRESS (ENTER) TO RECALL
1. Vac = 0.0 F = 60.00 Vdc = 0.0
2. Vac = 120.0 F = 60.00 Vdc = 0.0
3. Vac = 0.0 F = 60.00 Vdc = 0.0
Vac = 120.0_ F = 60.00 Vdc = 0.00 H
V = 0.00 F = 0.00 I = 0.00
P = 0.0 PF = 0.000 CF = 0.00
Conflicting with RANGE or V LIMIT
