Chroma 61605 - COUPLE Mode of Output (AC+DC, AC, DC)

Local Operation
3-15
supply positive and negative DC voltage without changing output
connector.
Chroma 61600 AC source have AC/DC/AC+DC output function, at DC output part, it’s still
different from really DC source, the reason as below:
1. The big ripple noise at DC output, it is because of AC source have no output capacitor.
2. The AC source output relay will switch off when the current over the specification, it will
cause output voltage interruption.
P.S. Normally the DC source will change to C.C. mode, then the output voltage slow
down to 0V.
3. Another major reason is, it cannot accept add/increase large capacitor, more than 20uF
at output side directly. It may cause output unstable and damage AC source.
For solving above weak point, we suggest that add a special fixture for sure and protection.
-
+
150uH / 8uH
L
N
1uF/630V
C1
47K / 10W
Ro
+
470uF/450V
C2
Capacitor
SW
10K / 20W
R
Discharge
SW
L
Vo
Ω
Ω
Resistor of
Discharger
Fixture Board
Bridge
Diode
Output
DC OUTPUT
61500 AC SOURCE
