Programmable AC Source 61605 User’s Manual
4-4
The AC source calibration steps are allowed to do individually, but it is
better to follow the calibration procedure step by step (step A, step B ...).
Or it may cause output and measurement errors.
Then press
SHIFT
, then
to change to next step.
In above step C of V OUT AND MEAS. ACCURACY CALI., the user should not turn on the
load. Press
ENTER
, then check the output voltage measured by DVM is about 15VAC.
This step is just to make sure the connection is correctly.
Then go to next step D. Press
ENTER
, check the output voltage measured by DVM is about
150VAC. Keyin the exact value measured by DVM, then press
ENTER
.
Then press SHIFT, then to change to next step.
In above step E of V OUT AND MEAS. ACCURACY CALI., the user should not turn on the
load. Press
ENTER
, then check the output voltage measured by DVM is about 30VAC.
This step is just to make sure the connection is correctly.
Then go to next step F. Press
ENTER
, check the output voltage measured by DVM is about
300VAC. Keyin the exact value measured by DVM, then press
ENTER
.
Step F is the final step of V OUT AND MEAS. ACCURACY CALI. Press
PAGE/EXIT
to exit
that page. Then display will show as below. Press
ENTER
to save the calibration results.
1. Users can press PAGE/EXIT to exit to the calibration choice page at
every step.
2. See the above display, if press PAGE/EXIT not to save the result, the
result of calibration still works, until turn the power off.
1. V OUT AND MEAS. ACCURACY CALI 150V RNG
C. ( ENTER ) THEN CHECK OUTPUT IS 15VAC
D. ( ENTER ) THEN KEYIN DVM MEAS. 150VAC
0.00_ V
1. V OUT AND MEAS. ACCURACY CALI 300V RNG
E. ( ENTER ) THEN CHECK OUTPUT IS 30VAC
F. ( ENTER ) THEN KEYIN DVM MEAS. 300VAC
0.00_ V
Press ( ENTER ) to save .
Press ( PAGE/EXIT ) not to save .
