Programmable AC Source 61605 User’s Manual
3-12
1. Move the cursor to the line of “POWER POWER ON STATUS : output = OFF_
ON STATUS : output =”.
2. Turn RPG to set output ON, then press POWER ON STATUS : output = ON
ENTER.
3. Press 1 , 2 , 0 , ENTER to Vac = 120.0 F=60.0_ Vdc = 0.0
set Vac=120.
4. Press 5 , 0 , then press ENTER Vac = 120.0 F=50.0 Vdc = 0.0
to set F=50.
5. Press 1 , 0 , then press ENTER Vac = 120.0 F=50.0 Vdc = 10.0
to set Vdc=10.
3.6.4 GPIB Address, RS-232C (with GPIB)
The AC source offers the mode of remote operation too. The user can set them on CONF
functional list (see 3.6). For details please refer to Chapter 7. Prior to remote operation the
user has to set the GPIB address 10 as below:
1. Move the cursor to the command ADDR = 30_
line of GPIB address.
2. Press 1 , 0 , ENTER to set address 10. ADDR = 10
Addressing space ranges from 1 to 30.
The AC source offers another remote operation through the RS-232C bus. Communication
protocol is set as follows:
To set parity=ODD, baud rate=19200.
1. Move the cursor to the command PARITY= NONE_ BAUD=9600
line of PARITY.
2. Turn RPG to select ODD, then PARITY=ODD BAUD=9600_
press ENTER.
3. The cursor moves automatically to
the setting position of “BAUD”. PARITY=ODD BAUD=19200
Turn RPG to select "19200", then
press ENTER.
The options of baud rate are 9600/19200. The options of parity are
EVEN/ODD/NONE.
