Pin Assignment of TTL Signal
A-1
Appendix A Pin Assignment of TTL Signal
9-Pin D-Type Female Connector:
Pin No.
Signal
Pin No.
Signal
1
GND
6
GND
2
/ Remote-Inhibit
7
GND
3
GND
8
/ FAULT-OUT
4
AC-ON
9
---
5
---
/ Remote-Inhibit: When vo
ltage level of this pin becomes LOW, it can inhibit the output
of AC Source (see 3.6.1).
AC-ON: When AC Source output voltage, this pin will become HIGH, and it becomes
LOW when quit output.
/ FAULT-OUT: The voltage level of this pin is HIGH if AC Source is in normal state. It
becomes LOW when AC Source is in protection state.
