Application
5-1
5. Application
5.1 General
Not only programming the steady sine output voltage and frequency, the AC Source 61705
also provides several powerful functions to simulate all kinds of power line disturbances.
Users can make the output change through a number of value in LIST mode (see 5.2), or
make the output change to its set value for a specific period of time in PULSE mode (see 5.3),
even make the output change to its set value step by step in STEP mode (see 5.4). With
these functions, it is easy to simulate cycle dropout, transient spike, brown out, and etc.
Not only measurements related to power in MAIN PAGE (see 3.3), the AC Source also can
achieve interharmonics waveform, a sweeping frequency superimposed on a static
fundamental wave (see 5.5).
5.2 List Mode (Optional Function)
On CHOICE PAGE (see 3.4), press 5 and ENTER to choose the LIST functional list.
The waveform programming of LIST mode is the assembly of the SEQuences. The output
waveform will start from SEQ=0, then SEQ by SEQ. The execution will stop until a SEQ
which TIME or CYCLE = 0, even the following SEQs had been set will not be executed.
COUPLE=INDIVIDUAL/Φ1+Φ2+Φ3: It sets the output function to individual or dependent
mode(Φ1+Φ2+Φ3).
1. SETUP 2.CONF 3.OUTPUT 4. MANUAL CALI
5.
LIST 6. PULSE 7.
STEP
8. INTERHAR
COUPLE =Φ1+Φ2+Φ3 [ LIST ]
TRIG = AUTO
COUNT: 0
<SHIFT> <ENTER> to Execute
COUPLE =INDIVIDUAL EDIT= Φ1 [ LIST ]
TRIG = AUTO
COUNT: Φ1=0 Φ2=0 Φ3=0
<SHIFT> <ENTER> to Execute
