TRIG=AUTO/MANUAL: It sets the way to trigger. AUTO: It will finish all COUNT number
when triggered. There is only one-way setting when the couple is set individual. MANUAL: It
will execute sequence waveform for once only. The phase needs to set toΦ1+Φ2+Φ3. It has
the same result in COUNT=1.
COUNT: It sets the whole number of times for executing sequences. COUNT = 0: infinity.
The source can set each phase count number in individual mode. Otherwise, it sets
Φ1+Φ2+Φ3 for the same count.
BASE = TIME / CYCLE: It sets the unit of sequence length.
Press SHIFT, then  to change to next page for sequence programming.
SEQ = 0 DEGREE = 0.0 [Φ1] [ LIST ]
Vs = 0.0 Fs = 60.00 DCs = 0.0
Ve = 0.0 Fe = 60.00 DCe = 0.0

SEQ = 1 DEGREE = 0.0 [Φ1] [ LIST ]
Vs = 0.0 Fs = 60.00 DCs = 0.0
Ve = 0.0 Fe = 60.00 DCe = 0.0

SEQ = 0 [Φ2] [ LIST ]
Vs = 0.0 Fs = 60.00 DCs = 0.0
Ve = 0.0 Fe = 60.00 DCe = 0.0

WAVE = A TIME = 0.0 ms

SEQ = 1 DEGREE = 0.0 [Φ2] [ LIST ]
Vs = 0.0 Fs = 60.00 DCs = 0.0
Ve = 0.0 Fe = 60.00 DCe = 0.0

WAVE = A TIME = 0.0 ms

