Chroma 61705 - Save, Recall, and Protection

Local Operation
3-17
3.8 Save and Recall
The AC Source offers two modes for the user to save and recall output setting or system data.
They are described in 3.8.1 and 3.8.2.
3.8.1 Save and Recall Output Setting
The AC Source offers nine channels for users to save a set of frequently used Vac, F, Vdc,
and to recall them for future use.
Under the MAIN PAGE:
Press SHIFT then PAGE/EXIT to run the SAVE function. The display will show as below:
Users can press 1 - 9 to select a channel, then press ENTER to save the output setting.
Press PAGE/EXIT to return to MAIN PAGE.
Recalling from memory channel to MAIN PAGE is shown as follows. In MAIN PAGE, press
SHIFT then

/ - to run the RECALL function. The display appears as below:
Users can press 1 - 9 to select a channel, then press ENTER to recall the output setting.
Afterward the display returns to MAIN PAGE automatically.
If the recalled settings are out of RANGE or over the V LIMIT (see 3.5.2, 3.5.3), the display
will show the following:
CHOICE 1-9, PRESS <ENTER> TO SAVE
1_ Vac1= 0.0 Vdc1= 0.0
Vac2= 0.0 Vdc2= 0.0
Vac3= 0.0 Vdc3= 0.0 F=60.00
CHOICE 1-9, PRESS <ENTER> TO RECALL
1_ Vac1= 100.0 Vdc1= 20.0
Vac2= 100.0 Vdc2= 20.0
Vac3= 100.0 Vdc3= 20.0 F=60.00
Vac1 = 0.0_ Vac2 = 0.0 Vac3 = 0.0 H
Freq = 60.00 Pt = 0.0
Vrms Φ1 = 0.00 Φ2 = 0.00 Φ3 = 0.00

I rms Φ1 = 0.00 Φ2 = 0.00 Φ3 = 0.00

