Chroma 61705 - SETUP Functional List

Local Operation
3-5
The definitions of measurement parameters are:
Pt
:
It is the measurement readings of total Power in Watts.
V
:
It is the measurement readings of Voltage in Volts. (True RMS measurement)
I
:
It is the measurement readings of Current in Amperes. (True RMS measurement)
Freq
:
It is the output frequency in Hertz.
P
:
It is the true Power measurement in Watts.
PF
:
It is the Power Factor, and its calculation formula = true power/ (Vrms × Irms)
CF
:
It is the Crest Factor, and its calculation formula = Ipeak/Irms.
Vdc
:
It is the DC composition measurement readings of Voltage in Volts.
Idc
:
It is the DC composition measurement readings of Current in Amperes.
Ip
:
It is the peak current measurement in Amperes.
Is
:
It is the I surge, and only measured from the occurrence of output transition as
defined in 3.5.8.
VA
:
It is the Apparent Power in Watts, and its calculation formula = Vrms × Irms.
VAR
:
It is the calculation formula =
VA P
2 2
−
Press  or  to move the cursor to the measurement column, and then use RPG to change
the measurement items as desired.
3.4 CHOICE PAGE (Functional List Choice)
Users can press PAGE/EXIT to change to CHOICE PAGE from MAIN PAGE or functional list
pages.
Users can press 1 - 4 to choose an operational list item, then press ENTER to confirm it.
The display will switch to MAIN PAGE by pressing PAGE/EXIT on CHOICE PAGE.
3.5 SETUP Functional List
On CHOICE PAGE (see 3.4), press
1
then
ENTER
to choose the SETUP functional list.
PAGE CHOICE = 1_
1.
SETUP 2.CONF 3.OUTPUT 4. MANUAL CALI
5. LIST 6. PULSE 7. STEP 8. INTERHAR
PAGE CHOICE = 1_
1. SETUP 2.CONF 3.OUTPUT 4. MANUAL CALI
5. LIST 6. PULSE 7. STEP 8. INTERHAR
