Programmable AC Source 61705 User’s Manual
1-8
1.4.3 The Rear Panel (with USB & Ethernet)
Table 1-2 Description of Rear Panel
Item
Name
Description
1
Ext. Ref.
A BNC connector to control waveform amplitude via external analog
(simulated).
2
USB
Connecting AC source and PC for communication.
3
IP Reset
Reset the IP address.
4
LAN
Connecting AC source and PC for network communication.
