General Information
1-7
Item
Name
Description
1
Label
The label includes model number, serial number of the AC
Source.
2 Ext. Ref.
The BNC connector inputs control waveform amplitude from
external analog signal. (This function is reserved now.)
3 RS-232C
The 9-pin, D-type female connector transfers control commands
to and from the remote PC for remote operation.
4 GPIB Connector
A remote controller using GPIB bus is connected to the AC
Source through this connector for remote operation.
5 TTL SIGNAL
The 9-pin, female connector transmits the control signals
(fault_out, remote inhibit, and AC_ON). (See Appendix A)
6
Warning Label
A warning for the leakage current.
7
Output Connector
This connector outputs power to the loading device.
8
Remote Sense
Connector
It senses directly at the terminals of the load to eliminate any
voltage drop on the connecting cable. Reverse polarity is not
allowed.
9
Power Line in
Connector
Power line input is connected to the AC Source through this
connector.
