Programmable AC Source 61705 User’s Manual
3-18
1. The function to save and recall output settings is for MAIN PAGE
settings only. Other parameters are ignored.
2. If V_SET=ALL (see 3.7.1), the recall settings for MAIN PAGE are
defined to Vac1, Vdc1.
3.8.2 Save and Recall System Data
The AC Source offers three memory groups for users to save the system data and to recall
them for later use. The system data contain all parameters in function lists such as
measurement settings, SETUP (see 3.5), CONF (see 3.6) and OUTPUT (see 3.7). In the
CHOICE PAGE (see 3.4
), press SHIFT and PAGE/EXIT to run the SAVE function. The
displays are shown as below.
Press 1 - 3 to choose the group to save, then press ENTER to confirm. The display
will show the saving status message about three seconds as below.
Then, press PAGE/EXIT to return to CHOICE PAGE.
Recalling the system data from memory group is shown as follows. In CHOICE PAGE,
press
SHIFT then

/ - to run the RECALL function. The display appears as below:
Save all parameters to Group ( 1 -
3 ) : 1_
Save all parameters to Group ( 1 -
3 ) : 1_
Saving now, do not shut down ........
Conflicting with RANGE or V LIMIT
Press <ENTER> key to Exit
PAGE CHOICE = 1_
1. SETUP 2.CONF 3.OUTPUT 4. MANUAL CALI
5. LIST 6. PULSE 7. STEP 8. INTERHAR
