SEQ: the number of sequence. All sequences must start with zero. The maximal number of
SEQ is 99.
DEGREE: the phase angle when the sequence starts.
Vs, Fs, DCs: the initial waveform when the sequence starts.
Ve, Fe, DCe: the final waveform when the sequence ends.
WAVE = A / B: the waveform selection (see 3.6.2).
TIME / CYCLE: the length of sequence.
After setting sequences, press PAGE/EXIT to exit to LIST mode page. Press SHIFT and
ENTER to change to execution page. The LCD shows _TRIG_ON is under action, and *
STOP * is the triggering status at present. Press ENTER to trigger. Then the LCD shows
status * RUNNING * and TRIG_OFF that is waiting for users to stop the LIST waveform output.
The LCD shows * STOP * when the AC Source executed all sequences and COUNT.
SEQ = 0 [Φ3] [ LIST ]
Vs = 0.0 Fs = 60.00 DCs = 0.0
Ve = 0.0 Fe = 60.00 DCe = 0.0
WAVE = A TIME = 0.0 ms
SEQ = 1 DEGREE = 0.0 [Φ3] [ LIST ]
Vs = 0.0 Fs = 60.00 DCs = 0.0
Ve = 0.0 Fe = 60.00 DCe = 0.0
WAVE = A TIME = 0.0 ms
_TRIG_ON * STOP * [ LIST ]
Vrms Φ1 = 0.00 Φ2 = 0.00 Φ3 = 0.00
I rms Φ1 = 0.00 Φ2 = 0.00 Φ3 = 0.00
_TRIG_OFF * RUNNING * [ LIST ]
Vrms Φ1 = 0.00 Φ2 = 0.00 Φ3 = 0.00
I rms Φ1 = 0.00 Φ2 = 0.00 Φ3 = 0.00
