Programmable AC Source 61705 User’s Manual
1-2
Model
61705
AC OUTPUT RATING
Max. Power
12000 VA
Power Per Phase
4K VA
Voltage
Range
150V / 300V
Output Voltage
0~150V/0~300V, 0~140V/0~280V@>1000Hz
Accuracy
0.2%+0.2%F.S.
Resoluction
0.1 V
Distortion
0.3% @50/60Hz
1.5%15- 1.2KHz
Line Rregulatoin
0.1%
Load Regulation
0.2%
Temp. Coefficient
0.02% per degree from 25°C
Max. Current (per phase)
R.M.S.
32A / 20A
Peak
192A / 96A
Frequency
Range
DC, 15-1.2K Hz
Accuracy
0.15%
Phase
Range
0 ~ 360°
Resolution
0.3°
Accuracy
<0.8°@50/60Hz
DC OUTPUT RATING (per phase)
Power
2K W
Voltage
212V / 424V
Current
16A / 8A
INPUT 3-PHASE AC POWER (per phase)
Voltage range
∆:200-240 V
LL
Y: 346-415 V
LL
Frequency range
47-63 Hz
Current
45A Max.
Power Factor
0.98 Min.
MEASUREMENT
Voltage
Range
150V / 300V
Accuracy
0.2%+0.2%F.S.
Resolution
0.1 V
Current
Range (peak)
192A
Accuracy (r.m.s.)
0.4%+0.3%F.S.
Accuracy (peak)
0.4%+0.6%F.S.
Resolution
0.01 A
Power
Accuracy
0.4%+0.4% F.S.
Resolution
0.1 W
Others
Efficiency
82 %
Size (W×H×D)
483 mm × 799 mm × 630 mm
Weight
170 Kg
Protection
UVP, OCP, OPP, OTP, FAN
Temperature range
