Programmable AC Source 61705 User’s Manual
3-10
Press
SHIFT
, then

to change to next page.
POWER ON STATUS : [ CONF ]
Output = OFF Freq = 60.00
Vac = 0.0
Vdc = 0.0

REMOTE INHIBIT= OFF [ CONF ]
GPIB ADD= 30 BAUD= 19200
WAVEA[Φ1]= SINE
WAVEB[Φ1]= SINE

WAVEA[Φ2]= SINE
WAVEB[Φ2]= SINE
WAVEA[Φ3]= SINE

WAVEB[Φ3]= SINE

REMOTE INHIBIT= OFF [ CONF ]
GPIB ADD= 30 BAUD= 19200
WAVEA[Φ1]= CSIN MODE= THD PER= 0.0 %
WAVEB[Φ1]= CSIN MODE= THD PER= 0.0 %

WAVEA[Φ2]= CSIN MODE= THD PER= 0.0 %
WAVEB[Φ2]= CSIN MODE= THD PER= 0.0 %
WAVEA[Φ3]= CSIN MODE= THD PER= 0.0 %

WAVEB[Φ3]= CSIN MODE= THD PER= 0.0 %

PAGE CHOICE = 2_
1. SETUP 2.CONF 3.OUTPUT 4. MANUAL CALI
5. LIST 6. PULSE 7. STEP 8. INTERHAR
